Mindman MVAA-180 Series: Manifold – MVSC1-180-3B12-NPT
$57.00
Manifold, Applicable: MVAA-180 Series, Manifold Type: 3-Port Straight-Piping Type, Number of Manifold Stations: 12, Port Thread: NPT Thread
10000 in stock
Features
● Port Diameter Code 6A
● Port Diameter Size 1/8
● Number of Ports 3-Port,5-Port
● Operating Fluid Air
● Operating Pressure Range 3A2, 4A2: 0~0.8 MPa,
●3A1, 4A1: 0.15~0.8 MPa
| Item | Specification |
|---|---|
| Bore No. | 6A |
| Port size | 1/8 |
| No. of port | 3, 5 |
| Medium | Air |
| Operating pressure range | 3A2, 4A2: 0~0.8 MPa 3A1, 4A1: 0.15~0.8 MPa |
| Proof pressure | 1 MPa |
| Effective orifice | 12 mm² |
| Pilot pressure range | (0.45×P※ + 0.1)~0.8 MPa |
| Ambient temperature | −5~+60°C (No freezing) |
| Weight | 61g~84g |
| Remark | ※ P: operating pressure. |
