Mindman METS2-14 Series: Accessory Kit – AK-ET1-14
SKU: AK-ET1-14
$380.00
Accessory Kit(With Light Shield & Bolts)
10000 in stock
Features
● The modular product saves design and assembly time, greatly boosting development efficiency.
● A one-piece extruded-aluminum body gives a good rigidity-to-weight ratio.
● Multiple motor-mount side positions give more machine-design options.
● Custom service (special styles) available on request.
Specification
| Item | Specification |
|---|---|
| Position repeatability (mm) | ±0.01 |
| Lead (mm) | 5~20 |
| Max. speed (mm/s) | 250~1000 |
| Stroke (mm) | 10: 100~1000 / 50 pitch 14: 100~1000 / 50 pitch 17: 100~1200 / 50 pitch |
| Ball screw O.D. | 10: C7 ø16 14: C7 ø16 17: C7 ø20 |
| Home sensor | EE-SX672 (NPN) |
| AC servo motor (standard) | 10: 50W, 100W 14: 200W 17: 200W, 400W |
| Coupling (mm) (standard) | 10: 10×8 14: 10×14 / 10×11 17: 10×14 |
| Max. payload (kg) (standard) | 10: Horizontal: 18~50, Vertical: 3~12 14: Horizontal: 35~95, Vertical: 6~27 17: Horizontal: 75~120, Vertical: 14~40 |
| Rated thrust (N) (standard) | 10: 42~170, 85~341 14: 174~683 17: 173~694, 347~1388 |
| AC servo motor (high power) | 10: 200W, 400W 14: 400W 17: 750W |
| Coupling (mm) (high power) | 10: 10×14 / 11 17: 10×19 |
| Max. payload (kg) (high power) | 10: Horizontal: 18~50, Vertical: 3~12 14: Horizontal: 40~110, Vertical: 8~33 17: Horizontal: 83~120, Vertical: 25~50 |
| Rated thrust (N) (high power) | 10: 174~683, 348~1366 14: 347~1388 17: 640~2563 |
| Sensor switch | RLT |
