Mindman MESH2 Series: Accessory Kit – AK-ES3-20

Name: Mindman MESH2 Series: Accessory Kit - AK-ES3-20 - Mindman
SKU: AK-ES3-20
Price: 380.00 USD
Availability: InStock

SKU: AK-ES3-20

$380.00

Accessory Kit(With Light Shield & Bolts), Applicable MESH2 Spec20

10000 in stock

Features
●Spec: 16, 20 Applicable Motor: 20, 28 Frame,
●Max Stroke: 50 mm, Max Speed: 50, 100, 400 mm/s.

Item	Specification
Size	16, 20
Position repeatability	±0.02
Lead	16: 2 mm 25: 2, 8 mm
Maximum speed (*1)	Motor SM/BM: ≤50~≤400 mm/s Motor OBM: ≤50~≤200 mm/s
Work load (*2)	Horizontal: 3 kg (16); 1.5, 6 kg (20) Vertical: 0.8 kg (16); 0.8, 1.8 kg (20)
Pushing force (*1,3,4)	18~195 N
Max. stroke length	16: 100 mm 25: 100 mm
Encoder	Incremental A/B/Z (4000PPR)
Motor size	16: 20 mm 25: 28 mm
Rated voltage	DC 24V ±10%
Sensor switch	RLT
Remark	1. The speed and force may change depending on the cable length, load, stroke and mounting conditions. 2. The maximum load capacity decreases as the speed increases. 3. The accuracy of pushing force is ±20%. 4. Pushing force for MESF2 is from 30% to 90%.

MESH2 Order Example
