Mindman MCQV3L Series: Pin(Applicable YS Fitting) – PIN-Q2-80-S

Name: Mindman MCQV3L Series: Pin(Applicable YS Fitting) - PIN-Q2-80-S - Mindman
SKU: PIN-Q2-80-S
Price: 900.00 USD
Availability: InStock

SKU: PIN-Q2-80-S

$900.00

Pin, Applicable YS Fitting(PIN-S), Applicable MCQV3L Cylinder Inner Dia.80mm

10000 in stock

Click to view the Mindman MCQV3L catalog.

Features
● Lubrication-free
Uses oil-impregnated alloy and special bearing bushings so the piston rod needs no lubrication.
● High quality, durable
Cylinder tube of aluminum alloy with anodized coating for greater wear and corrosion resistance.
● ISO 15552 Standard Spec
Made to international standard ISO 15552; most parts are interchangeable.
● Diverse brackets
Various fixed and non-fixed brackets available.

Specification

Item	Specification
Tube I.D. (mm)	63, 80
Medium	Air
Operating pressure range	0.15~1 MPa
Proof pressure	1.5 MPa
Ambient temperature	−5~+60°C (No freezing)
Available speed range	50~500 mm/sec
Holding force	Max. 2710 N, Max. 3690 N
Backlash	1mm or less
Sensor switch	RDC(V), RQC(V), RDT, RQT, RCA
Sensor switch holder	RC(V): DT7-1, DT7-2 RT: DT-1, DT-2 RCA: HV1, HV2

Order Example

MCQV3L Order Example

Mindman MCQV3L Series: Pin(Applicable YS Fitting) – PIN-Q2-80-S
