Mindman MAL403 Series: Air Combination Unit(Lubricator) – MAL403-10A-NPT

Name: Mindman MAL403 Series: Air Combination Unit(Lubricator) - MAL403-10A-NPT - Mindman
SKU: MAL403-10A-NPT
Price: 64.40 USD
Availability: InStock

SKU: MAL403-10A-NPT

$64.40

Air Combination Unit(Lubricator), Port Diameter: 3/8, Bowl Material: PC Bowl, Level Switch: Without, Flow Direction: Left¡úRight, Bracket: Without, Port Thread: NPT Thread

10000 in stock

Click to view the Mindman MAL403 catalog.

Features
● Port Diameter Code 8A, 10A, 15A
● Port Diameter Size 1/4, 3/8, 1/2
● Operating Fluid Air
● Max Operating Pressure 1 MPa
● Withstand Pressure 1.5 MPa
● Ambient Temperature £5~£«60℃ (Non-Freezing)

Specification

Item	Specification
Bore No.	8A, 10A, 15A
Port size	1/4, 3/8, 1/2
Medium	Air
Max. operating pressure	1 MPa
Proof pressure	1.5 MPa
Ambient temperature	−5~+60°C (no freezing)
Lubricating oil capacity	200 cm³
Min. flow for oil drip	8A: 30 l/min, 10A: 65 l/min, 15A: 80 l/min
Recommended lubricating oil	Turbine oil ISO-VG32
Optional attachment	C type bracket
Weight	410 g

Order Example

MAL403 Order Example
