Mindman BN-7M3 Series: 3-Way Solenoid Valve – BN-7M31-8-F-24
SKU: BN-7M31-8-F-24
$385.00
3-Way Solenoid Valve, Port Diameter: Rc1/4, Solenoid Protection Rating: DC Standard, Rated Voltage: DC24V
10000 in stock
Features
● Port Diameter Size: Rc1/4,
●Operating pressure range: 0~0.7 MPa, withstand pressure: 1.05 MPa.
Specifications
| Item | Specification |
|---|---|
| Port Size Code | 8A |
| Port Size | Rc1/4 |
| Valve Type | 3/2 (3-port, 2-position) |
| Working Fluid | Air |
| Operating Pressure Range | 0~0.7 MPa |
| Proof Pressure | 1.05 MPa |
| Effective Area | 2.5mm² |
| Ambient Temperature | -10°C~40°C (non-freezing) |
| Response Time | 10ms |
| Rated Voltage | AC110V, 220V (50/60Hz), DC24V |
| Power Consumption | Startup: AC 20/17VA, DC 6W; Holding: AC 12/9VA, DC 6W |
| Voltage Tolerance | ±10% |
| Insulation Class | E |
| Weight | 0.4 kgf |
Ordering Code
BN-7M 31-8-E-110
Model
Actuation Type
31 : 3-Port
Port Size
8 : Rc 1/4
Solenoid Protection
E : AC Standard
F : DC Standard
G : AC Waterproof
H : DC Waterproof
F : DC Standard
G : AC Waterproof
H : DC Waterproof
Rated Voltage
24 : DC24V
110 : AC110V
220 : AC220V
110 : AC110V
220 : AC220V
