Mindman VMG Series: Vacuum Pickup Unit(Rectangular Universal Type) – VMG-EXP-2618-P11L-1.5

Name: Mindman VMG Series: Vacuum Pickup Unit(Rectangular Universal Type) - VMG-EXP-2618-P11L-1.5 - Mindman
SKU: VMG-EXP-2618-P11L-1.5
Price: 241.00 USD
Availability: InStock

SKU: VMG-EXP-2618-P11L-1.5

$241.00

Vacuum Pickup Unit(Rectangular Universal Type,-Wayfor Type Mount Plate), Mounting Plate Size: 2618, Sponge Cup Rows: Cup Array(Bore Diameter?40,11 Row,94 Suction Cup), Suction Cup Spec: None Suction Cup, Mounting Bracket: Coupling Mounting Hole ø1.5

10000 in stock

Click to view the Mindman VMG catalog.

Features
●For robot arms handling large workpieces by suction.
●Pickup surfaces: full sponge and suction-cup array.
●Built-in high-flow vacuum generator. Max suction flow: 760 l/min guaranteed (rated value for 3 built-in ejectors).
●Vacuum-pump-compatible version available.
●After fixing the robot-arm flange plate to the arm, it slides in for easy installation, improving operability and safety.

Specification

Item	Specification
Number of rows of holes	5, 7, and 11 rows
Fluid medium	Air, Vacuum *1
Operating pressure range	0.3~0.7MPa (Only for Vacuum Generator spec.)
Rated supply pressure	0.5MPa (Only for Vacuum Generator spec.)
Noise	70dB(A) (Only for Vacuum Generator spec.)
Operating vacuum pressure	−100~0kPa (Only for Vacuum Pump compatible spec.)
Operating temp. range	5~50°C (No freezing)
Accessory 1	Robot flange mounting plate (P.C.D. 31.5, 40, 56, 80, 100), Digital Pressure Sensor with 3-color dual display, Push-in fitting for air piping
Accessory 2	Fixed orifice: Suppresses vacuum degradation due to leakage from non-absorbed areas by attaching an orifice to regulate the flow rate.
Remark	1. "Fluid medium: Vacuum" is only for vacuum pump compatible types. 2. Fixed orifice is available as an option.

Order Example

VMG Order Example
