Mindman VLG Series: Vacuum Pickup Unit(Single-Row Type/Cup Array) – VLG200S-P2L-15BS-161

Name: Mindman VLG Series: Vacuum Pickup Unit(Single-Row Type/Cup Array) - VLG200S-P2L-15BS-161 - Mindman
SKU: VLG200S-P2L-15BS-161
Price: 324.00 USD
Availability: InStock

SKU: VLG200S-P2L-15BS-161

$324.00

Vacuum Pickup Unit(Single-Row Type/Cup Array), Length: 200mm, Number of Rows: 2 Row, Suction Cup Diameter: ø15mm, Suction Cup Material: Silicone, Vacuum Generator: 161

10000 in stock

Click to view the Mindman VLG catalog.

Features
● For robot arms handling large workpieces by suction
● Three pickup-surface types: sponge (ring, full-sponge) and suction-cup array
● Built-in high-flow vacuum generator; max suction flow: 760 l/min guaranteed (rated value for 3 built-in ejectors).
Vacuum-pump-compatible version available
● After fixing the robot-arm flange plate to the arm, it slides in for easy installation
Improves operability and safety.

Specification

Item	Specification
Fluid medium	Air
Operating pressure range	0.3~0.7MPa
Rated supply pressure	0.5MPa
Operating temp. range	5~50°C (No freezing)
Mounting on robot	Robot flange mounting plate (P.C.D. 31.5) (sold separately) *1
Remark	*1. Robot flange mounting plate (sold separately) is not available for 500 mm and 600 mm length types.

Order Example

VLG Order Example

Mindman VLG Series: Vacuum Pickup Unit(Single-Row Type/Cup Array) – VLG200S-P2L-15BS-161
