Mindman MCMI Series: Sensor – RDT
$33.00
Sensor, Applicable: MCMI Series Pneumatic Cylinder, Model: RDT
10000 in stock
Features
● Lubrication-free
Uses oil-impregnated alloy and special bearing bushings so the piston rod needs no lubrication.
● High quality, durable
Cylinder of high-grade stainless steel for greater wear and corrosion resistance.
● ISO 6432 Standard Spec (?8~?25)
Made to international standard ISO 6432; most parts are interchangeable.
● Diverse bracket types
Various brackets available for both fixed and movable mounting.
● Port threads available in Rc or NPT
● Magnet fitted across the whole series
| Item | Specification |
|---|---|
| Tube I.D. (mm) | 8, 10, 12, 16, 20, 25, 32, 40 |
| Port size | M5×0.8, G1/8, G1/4 |
| Medium | Air |
| Max. operating pressure | 0.7 MPa |
| Min. operating pressure | 0.06~0.23 MPa |
| Proof pressure | 1 MPa |
| Ambient temperature | -5~+60°C (No freezing) |
| Lubricator | Not required |
| Available speed range | 50~750 mm/sec |
| Max. allowable kinetic energy | Cushion pad 0.02~1.2J, Adjustable cushion 0.4~2.35J |
| Sensor switch | RDC, RQC, RDT, RQT, RCM |
| Sensor switch band | R*C: BKC-1 (Not for R*CV angle cable) R*T: BKT-1 RCM: BM8~BM40 |
