Mindman MAF200 Series: Air Combination Unit(Precision Filter) – MAF200D-6A-B

Name: Mindman MAF200 Series: Air Combination Unit(Precision Filter) - MAF200D-6A-B - Mindman
SKU: MAF200D-6A-B
Price: 62.40 USD
Availability: InStock

SKU: MAF200D-6A-B

$62.40

Air Combination Unit(Precision Filter), Model: Standard, Filtration Rating: 0.3¦μm, Port Diameter: 1/8, Bowl Material: PC Bowl(PC), Flow Direction: Left¡úRight, Bracket: With Bracket(L Type Bracket), Port Thread: Rc Thread

10000 in stock

Click to view the Mindman MAF200 catalog.

Features
● Port Diameter Code 6A, 8A
● Port Diameter Size 1/8, 1/4
● Operating Fluid Air
●Max operating pressure (Note) 0.05~1 MPa
● Withstand Pressure 1.5 MPa
● Ambient Temperature £5~£«60℃ (Non-Freezing)
● Filtration Rating 0.3¦μm,0.01¦μm

Specification

Item	Specification
Bore No.	6A, 8A
Port size	1/8, 1/4
Medium	Air
Operating pressure range (*1,2)	0.05~1 MPa
Proof pressure	1.5 MPa
Ambient temperature	−5~+60°C (No freezing)
Filter element	Standard: 40µm Option: 5µm
Drain capacity	9.5 cm³
Optional attachment	L type bracket
Weight	187 g
Remark	1. Semi-auto drain (N.O. type): The drain port automatically discharges accumulated water when pressure is below 0.05 MPa. 2. Auto drain (N.C. type): Residual water remaining in the bowl after air shut-off or drainage is normal. 3. Poor air quality may cause product malfunction. Installing an upstream pre-filter (e.g., 40 µm) is recommended. 4. Bowls for semi-auto drain and auto drain valve (D) are not interchangeable.

Order Example

MAF200 Order Example

Mindman MAF200 Series: Air Combination Unit(Precision Filter) – MAF200D-6A-B
